Description
Compact double-acting air cylinder (ASA series) featuring a 40 mm bore and a long 250 mm stroke. The FA/S configuration combines a front flange (FA) with a rear swivel eye (S) for flexible installation in feed systems, clamping jigs and other automated functions on heavy-duty woodworking machines.
Key features
-
40 mm bore delivers strong pushing and pulling force
-
250 mm stroke length for extended travel applications
-
FA front flange for rigid face-mounting; S rear swivel eye for self-aligning pivot
-
Double-acting design ensures positive extend and retract cycles
-
Hard-anodised aluminium barrel and chrome-plated steel piston rod for long service life
-
NBR seals, factory lubricated—ready for plug-and-play replacement (OEM 4694H)
Specifications
-
Part number: 4694H
-
Bore: 40 mm
-
Stroke: 250 mm
-
Mounting style: FA front flange / S rear swivel
-
Operating pressure: 2 – 8 bar (check system spec)
-
Temperature range: –10 °C to +60 °C
-
Port threads: G 1/4ʺ (female)
-
Media: filtered compressed air
-
Function: double-acting pneumatic actuator
-
Materials: anodised aluminium body, steel rod, NBR seals
A dependable spare for day-to-day woodworking-machinery automation—perfect for positioning feeders, clamps or other woodworking-tooling fixtures that require high-stroke air actuation.
