Description
Compact air-pressure regulator that fine-tunes the roller-pressure circuit on the front cover of industrial woodworking machines, ensuring consistent contact force and smooth feed.
Key features
-
Wide 0.5 – 9 bar (7 – 130 psi) adjustment range
-
SR200-08 body: lightweight cast-aluminium housing, corrosion-resistant finish
-
Knurled control knob with push-to-lock ring prevents drift
-
Dedicated gauge port (1⁄8 ″) for easy pressure monitoring (gauge not supplied)
-
¼ ″ BSP inlet/outlet threads for fast swap-over
-
Supplied ready-oiled and factory-set to 4 bar (OEM ref. 0029H)
Specifications
-
Part number: 0029H
-
Model: SR200-08
-
Pressure range: 0.5 – 9 bar (7 – 130 psi)
-
Max inlet pressure: 10 bar (145 psi)
-
Ports: ¼ ″ BSP female (in/out) + 1⁄8 ″ gauge port
-
Temperature range: –10 °C to +60 °C
-
Media: filtered, lubricated compressed air
-
Mounting bracket: rear tab slots (M5)
-
Body material: die-cast aluminium with epoxy coating
Essential for reliable woodworking-machinery operation—maintains steady roller force during feeding and other woodworking-tooling processes.
