Description
Machined from wear-resistant bronze, this bushing (LC001753S) provides a low-friction bearing surface while offering a flanged top for secure, bolt-through fastening. Swap it in whenever the original sleeve is worn, scored or out-of-tolerance.
Key features
-
Internal M12 × 1.75 thread for screw or stud engagement
-
Flanged head with four clearance holes for bolt-through fixing (see drawing)
-
Ø42 mm outer diameter ensures snug press-fit in the housing
-
37 mm overall length gives generous bearing surface area
-
Bronze alloy offers excellent galling resistance and long service life
Specifications
| Item | Value |
|---|---|
| Part number | LC001753S |
| Internal thread | M12 × 1.75 mm |
| Outside diameter (B) | 42 mm |
| Overall length (H) | 37 mm |
| Material | Bronze alloy |
| Mounting | Flanged top with four fixing holes |
A robust bronze sleeve that keeps critical shafts running smoothly in high-duty woodworking-machinery applications, supporting precise woodworking-tooling performance day after day.
