Carbide Inserts 22 × 20 × 2 mm – Triangular 3-Edge Knives
£3.12
Made from micro-grain tungsten carbide, these inserts feature a 30 ° factory bevel on each edge. When a corner dulls, simply rotate to the next one—no grinding or knife-setting required—keeping production moving and finish quality high. Key features Three cutting edges – rotate to a fresh edge in seconds Triangular profile provides excellent chip clearance […]
Avaliable
Description
Made from micro-grain tungsten carbide, these inserts feature a 30 ° factory bevel on each edge. When a corner dulls, simply rotate to the next one—no grinding or knife-setting required—keeping production moving and finish quality high.
Key features
-
Three cutting edges – rotate to a fresh edge in seconds
-
Triangular profile provides excellent chip clearance for profiling cuts
-
22 mm side / 20 mm inscribed circle fits many triangular insert pockets
-
30 ° polished bevel ensures a clean, tear-free surface
-
Supplied in protective trays to prevent edge chipping during handling
Specifications
| Item | Value |
|---|---|
| Side length (B) | 22 mm |
| Inscribed circle (H) | 20 mm |
| Thickness (a) | 2 mm |
| Edge count | 3 indexable sides |
| Material | Solid tungsten carbide (micro-grain) |
| Bevel angle | 30 ° |
| Typical use | Spiral planers, CNC router heads, moulder cutter-blocks |
A robust insert that helps high-speed woodworking-machinery maintain precise woodworking-tooling performance with minimal downtime.
