Cogged Timing Belt 8M-58-952 L – Part No. 3635B

Description

Designed for synchronous drives, this 8M-pitch cogged belt (58 mm width, 952 mm length) delivers positive, slip-free power transfer between motor and feed-roller or cutter-head sprockets in heavy-duty woodworking machines.

Key features

• 8 mm HTD tooth profile for high-torque, backlash-free drive

• 58 mm wide neoprene body with embedded glass-cord tension members

• 952 mm pitch length (119 teeth) fits common drive layouts – check sprocket count

• Oil-, abrasion-, and temperature-resistant construction

• Supplied pretensioned and ready to install (OEM ref. 3635B)

Specifications

• Part number: 3635B

• Belt profile: HTD 8M (8 mm pitch)

• Pitch length: 952 mm (119 teeth)

• Belt width: 58 mm

• Construction: neoprene rubber with glass-cord tensile members

• Operating temp: –20 °C to +100 °C

• Tensile strength: ≥ 9 000 N

• Typical use: motor-to-feed roller, cutter-head, or conveyor drives

An essential spare that keeps woodworking-machinery drive systems running smoothly and your woodworking-tooling lines at full production speed.
