Description
The replacement gearbox (0362B) bolts straight onto the original mounting plate. The 3-L layout provides three dedicated lubrication ports—fill, level and drain—making routine oil service simple. It arrives factory-filled and ready to run after coupling the shafts.
Key features
-
10.41 : 1 reduction delivers stable, repeatable output speed
-
3-L housing with separate fill / level / drain plugs for quick servicing
-
Precision-cut gears in a rigid cast-iron case minimise vibration and noise
-
Bolt pattern and shaft centres match the OEM drawing—no shimming required
-
Supplied with transit plugs and corrosion-inhibiting oil film
Specifications
| Item | Value |
|---|---|
| Part number | 0362B |
| Gearbox type | 3-L (triple-port lubrication) |
| Reduction ratio | 10.41 : 1 (input : output) |
| Mounting | Four-bolt base flange (match OEM pattern) |
| Lubrication | Factory-filled gear oil; top-up per service schedule |
| Input / output shafts | OEM diameters for this code |
A robust reducer that keeps woodworking-machinery drives running smoothly, delivering consistent torque for precise woodworking-tooling performance shift after shift.
