Description
This precision-ground spindle (1192LS) restores concentric, vibration-free rotation for horizontal cutter stations. The 50 mm journal seats directly in the OEM bearing set, while the 128 mm cutter seating length accepts profile heads, groovers, or stack tooling. A threaded end and keyway match the original hardware for quick, drop-in replacement.
Key features
-
Ø50 mm bearing journals ground to h6 tolerance for perfect bearing fit
-
128 mm cutter seating length (≈ 9″) handles single or stacked cutter-heads
-
Hardened and tempered alloy steel resists deflection at high RPM
-
Precision keyway and draw-bolt thread match the OEM tool-holder system
-
Supplied lightly oiled and capped to prevent corrosion in transit
Specifications
| Item | Value |
|---|---|
| Part number | 1192LS |
| Spindle type | Horizontal (left-side orientation) |
| Journal diameter | Ø50 mm |
| Cutter seating length | 128 mm (≈ 9 in.) |
| Overall length | OEM dimension for this code |
| Material / HRC | Through-hardened alloy steel, 58–60 HRC at journal |
| Keyway | 14 mm wide × 4.5 mm deep (verify against old shaft) |
| Thread | M24 × 2 draw-bolt (left-hand) |
A straight, rigid spindle that drives the cutter block, keeping the blades in perfect alignment for clean, accurate woodworking-tooling results.
