Description
Key features
-
Hydrodynamic oil film—internal pump ring maintains an even lubricant layer, eliminating metal-to-metal contact at high RPM.
-
40 mm precision bore—fits Leadermac and compatible spindle noses without extra sleeves.
-
140 mm outside diameter—drops straight into the OEM mounting bracket.
-
Dual pressure ports for easy connection to your central lube system.
-
Supplied pre-charged with preservative oil and sealed for transit.
Specifications
| Item | Value |
|---|---|
| Part number | 0006LS |
| Bearing type | Hydraulic outboard / hydrodynamic journal |
| Shaft bore | Ø 40 mm |
| Housing OD | Ø 140 mm |
| Lubrication ports | 2 (inlet / drain), BSP ⅛″ |
| Material | High-grade cast housing with bronze bearing shell |
| Application | Outboard support for horizontal spindles |
A critical support that keeps long spindles running true and protects both the cutter block and associated woodworking-tooling from vibration-induced wear.
