Description
Key features
-
Snap-action contacts deliver reliable, bounce-free signalling at high cycle rates.
-
Plunger/roller actuator suited to trip cams mounted on feed tables or fences.
-
IP66 metal housing resists dust and coolant splash in demanding shop environments.
-
Factory-wired NC + NO contact block—connect directly to PLC or safety relay.
-
Direct drop-in replacement wherever the parts list specifies 1877M.
Specifications
| Item | Value |
|---|---|
| Part number | 1877M |
| OEM reference | XCK-N2118G11 |
| Contact configuration | 1 NO + 1 NC (snap-action) |
| Actuator style | Top plunger with nylon roller |
| Housing rating | IP66, die-cast zinc |
| Cable entry | M20 × 1.5 (pre-fitted gland) |
| Electrical rating | 240 V AC, 3 A (inductive) |
| Operating temp. | –25 °C … +70 °C |
A robust position switch that helps safeguard woodworking machinery and the woodworking-tooling it drives.
