Description
Engineered ASA-series air cylinder combining a 40 mm bore with an extended 330 mm stroke. The FA/S configuration pairs a rigid front-flange (FA) with a rear swivel eye (S) for easy pivoting alignment. Two matching mounting screws are included for fast, drop-in replacement on heavy-duty woodworking machines.
Key features
-
40 mm bore delivers strong push/pull force
-
330 mm stroke length for long-travel applications
-
FA front flange + S rear swivel eye for versatile installation
-
Supplied with 2 OEM mounting screws (M10 × 35)
-
Double-acting design ensures positive extend & retract cycles
-
Hard-anodised aluminium barrel, chrome-plated steel piston rod
-
Factory-lubricated NBR seals for long, leak-free service (OEM 4628H)
Specifications
-
Part number: 4628H
-
Bore: 40 mm Stroke: 330 mm
-
Mounting style: FA (front flange) / S (rear swivel)
-
Included hardware: 2 × M10 mounting screws
-
Operating pressure: 2 – 8 bar Temp: –10 °C to +60 °C
-
Ports: G 1/4″ female
-
Function: double-acting pneumatic actuator
-
Body: anodised aluminium Rod: chrome steel
-
Media: filtered compressed air
A dependable spare for long-stroke woodworking-machinery automation—ideal for positioning feeders, clamps, or other woodworking-tooling fixtures that require extended air actuation.
