Weinig 170x25x35 Steel Roller | 10mm Keyway | Leadermac UK

Description

The Weinig 170-25-35 Feed Roller features a durable aluminium kernel coated in brown 70±5 ShA rubber. Built for wear resistance and consistent grip, it ensures smooth, non-marking feeding in Weinig moulders. Its compact 25mm rubber width is ideal for precision feed applications.

We also offer refurbishment services and the ability to rubberize in other compounds upon request—get in touch for details.

Also available:

• Weinig 170-50-35-10-3V (Item Nr. 111-0092)

• Weinig 140-22-30-3V (Item Nr. 111-0058)

• Weinig 140-25-30-3V (Item Nr. 111-0059)

---

Technical Specifications:

• Kernel Diameter (D): 150 mm

• Final Diameter with Rubber (D1): 170 mm

• Kernel Length (L): 28 mm

• Rubber Length (L1): 25 mm

• Bore (ƒå): 35 mm

• Keyway Width (U): 10 mm

• Fixing Screw Hole Centres Diameter (TK): N/A

• Item Number: 111-0089

• Gross Weight: 1.10 kg



View our complete feed rollers range.
